Over the past few months, I’ve shared a couple of Sudoku solvers here — some built with Dynamic Programming, others with Mixed-Integer Linear Programming (MILP). Both approaches work and are great learning exercises, but they each have their quirks when it comes to constraint formulation:
- In MILP, expressing “all-different” constraints means either crafting a set of linear inequalities or introducing auxiliary binary variables with Big-M tricks.
- Dynamic Programming is more algorithmic and procedural, which makes it less declarative.
This time, I wanted something cleaner — so I turned to Constraint Programming (CP) with Google OR-Tools.
The beauty is: With CP, Sudoku rules can be expressed almost exactly as you’d explain them to a human:
- Numbers in each row:
AllDifferent- Numbers in each column:
AllDifferent- Numbers in each 3×3 block:
AllDifferent
No manual encoding of constraints, no binary variables for every number — just the logical structure of the puzzle.
To push it further, I ran the model on the infamous “world’s hardest Sudoku”, and it solved it in fractions of a second. Best part? I didn’t need to tweak the model at all.
Why CP shines here:
- Declarative modeling: You state the rules, the solver figures out the search.
- Concise code: A handful of loops and
AllDifferentconstraints define the whole puzzle. - Solver efficiency: CP explores Sudoku search spaces very effectively.
- Extensibility: Want Killer Sudoku, Diagonal Sudoku, or Samurai Sudoku? Just add more constraints.
I’ve attached the full code below — the core is really just variable declarations plus three loops of AllDifferent constraints.
I’m curious:
- Who here has experimented with OR-Tools’ CP solver, and how do you think it stacks up against MILP for puzzles like this?
- Has anyone tried combining CP with custom search heuristics for exotic Sudoku variants?
"""Sudoku solver using Google OR-Tools CP-SAT.
This module exposes a single `solve` function that accepts a 9x9 grid
with zeros for blanks and returns a completed Sudoku grid.
"""
from ortools.sat.python import cp_model
def solve(puzzle):
"""Solve a standard 9×9 Sudoku with OR-Tools CP-SAT.
The puzzle is modeled as 81 integer decision variables with the
usual Sudoku constraints:
- Rows contain numbers 1..9 exactly once.
- Columns contain numbers 1..9 exactly once.
- Each 3×3 block contains numbers 1..9 exactly once.
Provided clues (non-zero entries) are enforced as fixed equalities.
Args:
puzzle: A 9×9 list of lists of ints. Use 0 to denote empty cells;
filled cells must be in the range 1..9.
Returns:
A 9×9 list of lists of ints representing a solved Sudoku grid.
"""
model = cp_model.CpModel()
# Decision variables: one IntVar per cell with domain 1..9
# cells[(r, c)] corresponds to the value in row r, column c (0-indexed).
cells = {}
for r in range(9):
for c in range(9):
cells[(r, c)] = model.NewIntVar(1, 9, f'cell_{r}_{c}')
# Constraints
# Rows & columns must contain all digits 1..9 exactly once.
for i in range(9):
model.AddAllDifferent([cells[(i, j)] for j in range(9)])
model.AddAllDifferent([cells[(j, i)] for j in range(9)])
# 3×3 subgrid constraints:
for br in range(3):
for bc in range(3):
block = [cells[(r, c)]
for r in range(br*3, (br+1)*3)
for c in range(bc*3, (bc+1)*3)]
model.AddAllDifferent(block)
# Fix given clues (non-zero cells) to their provided values.
for r in range(9):
for c in range(9):
if puzzle[r][c] != 0:
model.Add(cells[(r, c)] == puzzle[r][c])
solver = cp_model.CpSolver()
solver.Solve(model)
return [[solver.Value(cells[(r, c)]) for c in range(9)] for r in range(9)]
def main():
# Hardest ever Sudoku
initial_grid = [[8, 0, 0, 0, 0, 0, 0, 0, 0],
[0, 0, 3, 6, 0, 0, 0, 0, 0],
[0, 7, 0, 0, 9, 0, 2, 0, 0],
[0, 5, 0, 0, 0, 7, 0, 0, 0],
[0, 0, 0, 0, 4, 5, 7, 0, 0],
[0, 0, 0, 1, 0, 0, 0, 3, 0],
[0, 0, 1, 0, 0, 0, 0, 6, 8],
[0, 0, 8, 5, 0, 0, 0, 1, 0],
[0, 9, 0, 0, 0, 0, 4, 0, 0],
]
solution = solve(initial_grid)
print(solution)
if __name__ == "__main__":
main()
